Polaris Sportsman 400 500 ATV Service Manual | 2005-2009

Name: Polaris Sportsman 400 500 ATV Service Manual | 2005-2009
Brand: Polaris
SKU: POLARIS_2005SPORTSMAN400500
Price: 12.49 USD
Availability: InStock

$12.49 USD

Sale Sold out

Shipping calculated at checkout.

Quantity

POLARIS 2005-2009

Polaris Sportsman 400 500 • Service Manual

Complete OEM service manual for the 2005-2009 Polaris Sportsman 400 and Sportsman 500 ATVs, covering engine overhaul, carburetion, clutching, final drive, transmission, brakes, and full electrical diagnostics. Everything a technician or owner needs to service, repair, and maintain these capable four-wheelers. Delivered instantly as a fully searchable PDF compatible with any device. • Polaris original service manual

Adobe Acrobat (PDF) format
Fully searchable
Easily print any or all content
Everything needed to repair & maintain your ATV
Troubleshooting instructions, wiring diagrams, and reference material

Models Covered

2005 Polaris Sportsman 400 (A05MH42AB
AG
AH)
2005 Polaris Sportsman 500 (A05MH50AB
AC

Table of Contents

GENERAL INFORMATION
PERIODIC MAINTENANCE
ENGINE
FUEL SYSTEM / EFI
COOLING SYSTEM
CLUTCH & TRANSMISSION
FINAL DRIVE
SUSPENSION
STEERING
BRAKES
ELECTRICAL SYSTEM
BODY & FRAME
WIRING DIAGRAMS

What's Included

Complete engine disassembly and assembly procedures for single-cylinder liquid-cooled SOHC 4-stroke
Carburetor fuel system diagnostics including Mikuni BST jetting, float height, and pilot screw adjustment
Electrical, ignition, and charging system procedures including DC/CDI ignition and 3-phase regulator
Cooling system inspection, coolant change, and water pump service
Final drive, front gearcase, and axle service procedures
PVT clutch system service including drive clutch, driven clutch, and EBS clutch alignment
Front and rear suspension repair including MacPherson strut and progressive rate independent shock service
Steering system inspection, toe alignment, and tie-rod adjustment
Brake system inspection, hydraulic disc brake service, and fluid change
Transmission drum-shift disassembly, inspection, and reassembly
Periodic maintenance schedules, lubrication points, and oil change procedures
OEM specifications, torque tables, and jetting/clutch charts
High-resolution wiring diagrams and electrical schematics

Features

OEM-quality PDF (searchable and printable)
High-resolution diagrams and schematics
Works on PC, Mac, tablet, and mobile devices
Important: This is a digital PDF manual. No paper book will be provided.
